END OF MANUFACTURING, STOCK LIMITED

Dome, SDU8E, color camera module, 22X, 470 TVL, I/O board, NTSC, White

American Dynamics ADSDU8E22WION

Dome, SDU8E, color camera module, 22X, 470 TVL, I/O board, NTSC, White

ADSDU8E22WION - White NTSC camera kit comprising: ADSDU8E22N 22x SpeedDome Ultra VIII; ADSDUIOB I/O board base with memory & alarms (up to 4 I/Ps and 4 O/Ps)

SpeedDome Ultra 8E Programmable Dome Camera (22x optical zoom)
The SpeedDome Ultra 8E 22x series delivers excellent color images in scenes as dim as .02 lux. Zoom ability consists of 22x optical and 11x digital zoom for 242x total zoom. Like the 35x series, the 22x offers advanced programmable features including DSS, automatic home position, dome usage statistics, increased number of privacy zones, advanced on-screen text, and freeze frame on presets to conserve digital recorder hard drive space. Helpful onscreen text and indicators show the direction the dome is currently pointing, as well as the direction in which it is moving.

• Motion detection provides the ability to trigger multiple user-specified actions with motion tracking capabilities
• Improved privacy zones and patterns
• Supports additional number of third party protocols
• Continuous autofocus provides the clearest images during full range of motion
• Advanced on-screen display with titles provides the detail you need
• Supports SensorNet, RS-422, AD-UTC, Manchester and select manufacturers’ Protocols*
• Supports NTCIP protocol, designed specifically for the transportation market

* Compatibility with other manufacturers is based upon known current protocols and controllers at time of test. However, compatibility may be affected if other manufacturers make changes to their products.
